این سنسور در مسائل بهداشتی کاربرد دارد.
مشخصات فنی:
مشخصات فنی:
| Nominal pressure relative inbar | 0.1 | 0.16 | 0.25 | 0.40 | 0.60 | 1 | 1.6 | 2.5 | 4 | 6 | |
| Nominal pressure absolute inbar | 0.40 | 0.60 | 1 | 1.6 | 2.5 | 4 | 6 | ||||
| Overpressure in bar | 0.5 | 1 | 1 | 2 | 5 | 5 | 10 | 10 | 20 | 40 | |
| Burst pressure in bar | 1.5 | 1.5 | 1.5 | 3 | 7.9 | 7.5 | 15 | 15 | 25 | 50 | |
| Nominal pressure relative / absolute in bar | 10 | 16 | 25 | 40 | |||||||
| Overpressure in bar | 40 | 80 | 80 | 108 | |||||||
| Burst pressure in bar | 50 | 120 | 120 | 210 | |||||||
| Negative pressure | -1 ... 0 bar; Overload: 5 bar; Burst pressure: 7.5 bar | ||||||||||
| Vacuum resistance | P > 1 Bar: unrestricted | ||||||||||
| General Technical Data | |||||||||||
| Accuracy | > 0.4 Bar: < ± 0.125 % FSO < 0.4 Bar: < ± 0.25 % FSO |
||||||||||
| Measuring rate | 1/s | ||||||||||
| Long term stability | < ±0.1% FSO | ||||||||||
| Media |
Fuels, oils, gases, water |
||||||||||
| Temperature ranges | Fluid: -20 ... 85°C / -4 ... 185°F Environment: -20 ... 70°C / -4 ... 158°F Storage: -30 ... 80°C / -22 ... 176°F |
||||||||||
| Pressure port / housing | Stainless steel 1.4404 | ||||||||||
| Seal | FKM | ||||||||||
| Diaphragm | Stainless steel 1.4435 | ||||||||||
| Parts that come into contact with water | Pressure port, seals, diaphragm | ||||||||||
| Display | LC Display | ||||||||||
| Power supply | 2 x 3.6V lithium battery (1 / 2AA) | ||||||||||
| Battery life | 1.5 years standby | ||||||||||
| Protection | IP65 | ||||||||||
| Weight | ca. 300 g / < 1 lb | ||||||||||
