کنترل ولو فیشر سری FCV 103
- SIZE:. 12"
- TYPE & CLASS: 7611
- STYLE: FISHTAIL butterfly
- END CONNECTION ANSI CLASS: ANSI 150
- BODY MATARIAL : 316 SST
- FORWARD FLOW DIRECTION
- DISK & BALL MATARIAL: 316 SST
- SHAFT MATERIAL: 14-4PH SST
- SEAL & LINER MATERIAL: NITRILE
- ACHIATOR: 3-15 PSI
- AIR FAILS VALVE TO CLOSE
- AUXILIARY HAND WHEEL : 1074
- INLET TEMP : 239 ° F
- INLET PRESSURE : 32 PSIG
- ΔP SIZING : 5 PSI
- FLOW RATE : 6900 GPM
- REQUIRED FLOW COEFFICIENT Cv: 3152
